| Cutting Diameter (DC) | 1 mm | End Shape | Square |
| Connection Diameter Machine Side (DCONMS) | 4 mm | Usable Length (LU) | 48.5 mm |
| Depth of Cut Maximum (APMX) | 1.5 mm | Corner Radius (RE) | None |
| Overall Length (OAL) | 50 mm | Flute Type | Spiral |
| Cutting Edge Material | Carbide | Coolant Supply Property (CSP) | External |
| Coating | AlTiN | Decimal Equivalent | 0.0394″ |
| Flute Count (NOF) | 2 | Measurement Type | Metric |
| Flute Helix Angle (FHA) | 30 Degrees | Series/List # | M2SM |
| Shank Type | Round |
Product Features
| Country of Origin | USA |
Shipping Info
Package Length
2.55700
Package Width
.50800
Package Weight
.023
