| Cutting Diameter (DC) | 0.045″ | End Shape | Square |
| Connection Diameter Machine Side (DCONMS) | 1/8″ | Usable Length (LU) | 2.14″ |
| Depth of Cut Maximum (APMX) | 0.36″ | Corner Radius (RE) | 0″ |
| Overall Length (OAL) | 2-1/2″ | Flute Type | Spiral |
| Cutting Edge Material | Carbide | Coolant Supply Property (CSP) | External |
| Coating | AlTiN | Decimal Equivalent | 0.045″ |
| Flute Count (NOF) | 4 | Measurement Type | Inch |
| Flute Helix Angle (FHA) | 30 Degrees | Series/List # | M4SE |
| Shank Type | Round |
Product Features
| Country of Origin | USA |
Shipping Info
Package Length
3.80000
Package Width
.16000
Package Weight
.021
